Home >> Product Center

HPD2503 20FT Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION： Suitable for loading and unloading P4 or P7 pallets*1 、P6 or P1 pallets*2 FEATURES： *The main structure is welded from channel steel of high quality, which is strong, not easy to deform and able to bear collision. *The working surface is 530mm in height, in accordance with international standards, and can work with different kinds of scissor lift tables for loading and unloading cargo. *Wheels are made of ultra-wear-resistant natural rubber iron core wheel,front wheels are castor and rear wheels are fixed. *The tow bar has the function of traction. The tow bar can be locked when lowered. *Anti-collision function is designed under the tow bar. *The tow bar controls the brakes, which act on the rear wheels. The brake lever is adjustable when the tire wears out. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/HPD2503.pdf" target="">Detail</a>
HPD0808C 20FT Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION： Suitable for loading and unloading P4 or P7 pallets*1 FEATURES： *The main structure is welded from channel steel of high quality, which is strong, not easy todeform and able to bear collision. *The working surface is 530mm in height, in accordance with international standards, and can work with differentkinds of scissor lift tables for loading and unloading cargo. *Wheels are made of ultra-wear-resistant natural rubber iron core wheel,front wheels are castor and rear wheels are fixed. *The tow bar has the function of traction. The tow bar can be locked when lowered. *Anti-collision function is designed under the tow bar. *The tow bar controls the brakes, which act on the rear wheels. The brake lever is adjustable when the tire wears out. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/HPD0808C.pdf" target="">Detail</a>
BC2406 Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION： Suitable for loading and unloading P1,P6,P7,P9 palletsand LD1, LD2,LD3,LD4,LD6,LD7 containers.  FEATURES： *The main structure is welded from rectangular steel tube of high quality, which is strong, not easy to deform and able to bear collision. *The working surface is 520mm in height, in accordance with international standards, and can work with different kinds of scissor lift tables for loading and unloading cargo. *The front wheel steering system is the fifth wheel type that features heavy-duty ball bearing ring with diameter of 1100mm. *The tow bar has the function of traction. The tow bar can be locked when lifted.The towbar has two torsion springs, to assist the operator to lift the towbar easily. *The dolly is equipped with a buffer device to prevent the towbar from hitting the ground when it falls, so as to avoid the accident of injuring the operator. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/BC2406.pdf" target="">Detail</a>
BC0609 Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: Suitable for loading and unloading P1,P6,P7,P9 palletsand LD1, LD2,LD3,LD4,LD6,LD7 containers.  FEATURES: *The main structure is welded from channel steel of high quality, which is strong, not easy to deform and able to bear collision. *The working surface is 508mm in height, in accordancewith international standards, and can work with different kinds of scissor lift tables for loading and unloading cargo. *Wheels are solid heavy duty ones made of natural rubber, front wheels are castor and rear wheels are fixed. *The tow bar has the function of traction and brake. The tow bar can be locked when lifted. *Anti-collision function is designed under the tow bar, which is convenient for single-manoperation when towed by a tractor. *The brake will be activated when the tow bar is lifted . The brake lever is adjustable when thetire wears out. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/BC0609.pdf" target="">Detail</a>
BC1912 Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: Suitable for loading and unloading P1,P6,P7,P9 palletsand LD1, LD2,LD3,LD4,LD6,LD7 containers.  FEATURES: *The main structure is welded from channel steel of high quality, which is strong, not easy to deform and able to bear collision. *The working surface is 520mm in height, in accordancewith international standards, and can work with different kinds of scissor lift tables for loading and unloading cargo. *Wheels are solid heavy duty ones made of natural rubber, front wheels are castor and rear wheels are fixed. *The tow bar has the function of traction. The tow bar can be locked when lifted. Anti-collision function is designed under the tow bar, which is convenientfor single-man operation when towed by a tractor.  *The brake is controlled by the handle at the front.  *The rollers are all galvanized, designed by 4 rows and 50 rollers in total.  <a href="http://pro9636cc.pic28.websiteonline.cn/upload/BC1912.pdf" target="">Detail</a>
PD2008 Pallet Dolly

Pallet dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: Suitable for loading and unloading P1,P6,P7,P9 palletsand LD1, LD2,LD3,LD4,LD6,LD7 containers.  FEATURES: *The main structure is welded from channel steel of high quality, which is strong, not easy to deform and able to bear collision. *The working surface is 508mm in height, in accordancewith international standards, and can work with different kinds of scissor lift tables for loading and unloading cargo. *Wheels are solid heavy duty ones made of natural rubber, front wheels are castor and rear wheels are fixed. *The restraint lock has 4 different types: (A) L-shaped restraint lock*4; (B) T-shaped restraint lock*1; (C) 168 restraint lock *6; (D) 155 restraint lock*6. *After the vehicle is sandblasted, it can be hot-dip galvanized/sprayed/painted according to customer requirements. Body color, logo, number, etc. can also be specified. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/PD2008.pdf" target="">Detail</a>
SC2401 Baggage Cart

Baggage Cart

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: *Suitable for loading passenger luggage and bulk cargo.  FEATURES: *The whole vehicle frame is welded with high-quality steel. *The front axle is designed as a rotating steering mechanism. *The roof is designed as a collapsible (left and right folding) awning, especially suitable for rainy days. *The tow bar has the function of traction and brake. The tow bar can brake automatically when lowered. *The rear hook has a spring self-locking limit function with triple security protection, which willnot be disconnected when driving. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/SC2401.pdf" target="">Detail</a>
DC2408 DG Cart

Baggage Cart

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: *Suitable for loading various of dangerous goods.  FEATURES: *The whole vehicle frame is welded with high-quality steel. *Front steering system is fifth wheel type. *The frame is made of Anti-slip film faced birch plywood, Type A bond waterproof glue, R13anti-slip coefficient, color is brown. *The roof of the cart is designed as a circular one, and bothsides are designed with rain chutes for operation in rainy days. *The cart adopts left-side loading design, with fixed wallpanels installed on the right side. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/DC2408.pdf" target="">Detail</a>
SC0905 Baggage Cart

Baggage Cart

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION： *Suitable for loading passenger luggage and bulk cargo.  FEATURES：*The whole vehicle frame is welded with high-quality steel. *The front axle is designed as a rotating steering mechanism. *The frame is designed with a V-shaped panel and a sink in the middle of the frame. *The roof of the cart is designed as a circular one, andboth sides are designed with rain chutes for operation in rainy days. *The cart is designed with double sliding doors, which greatly facilitates baggage and cargo handling operations.The sliding door is light, and the two sides of the sliding door are equipped with safety locks for easy operation. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/SC0905BaggageCart.pdf" target="">Detail</a>
BT1702C Baggage Cart

Baggage Cart

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: *Suitable for loading passenger luggage and bulk cargo. FEATURES: *The whole vehicle frame is welded with high-quality steel. *The front axle is designed as a rotating steering mechanism. *The frame is designed with a V-shaped panel and a sink in the middle of the frame. *The roof of the cart is designed as a circular one, and both sidesare designed with rain chutes for operation in rainy days. *The tow bar has the function of traction and brake. The tow bar can be locked when lifted. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/BT1702C.pdf" target="">Detail</a>
BT2409 Baggage Cart

Baggage Cart

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: *Suitable for loading passenger luggage and bulk cargo.  FEATURES: *The whole vehicle frame is welded with high-quality steel. *Front steering system is fifth wheel type. *The frame is designed with a V-shaped panel and a sink in the middle of the frame. *The frame is made of Anti-slip film faced birch plywood, Type A bond waterproof glue, R13placed after folding, and there are binding rope. *The cart is designed to be loaded on the left and right sides, with two steel chains to preventthe passenger luggage and bulk cargo from falling off. *The tow bar has the function of traction and brake. <a href="http://pro9636cc.pic28.websiteonline.cn/upload/BT2409.pdf" target="">Detail</a>
XC1103C Container Dolly

Container dolly

市场价:￥0.00

价格:￥0.00

MAIN APPLICATION: *Suitable for loading and unloading LD1, LD2,LD3 containers. *Weight: About 655kg *Loading capacity: 1600kg *Max speed: 15km/h FEATURES： *The main structure is welded with high-quality steel and has a patterned walkway in the middle. *The front axle is designed as a rotating steering mechanism. *The turntable allows the container to rotate 360 degrees in any two directions and automaticallylocks every 90 degrees.  *The rollers are all galvanized and designed by2 rows and 22 rollers in total. *The tow bar has the function of traction and brake. The tow bar can be locked when lifted.<a href="http://pro9636cc.pic28.websiteonline.cn/upload/XC1103CContainerDolly.pdf" target="_blank" style="text-decoration: underline; color: rgb(227, 108, 9); font-size: 16px;"> Details</a>
